SPECIFICATIONS:
Builder Shannon Yachts, Bristol , Rhode Island
Designer Walter Schulz & Assoc.
Length on Deck 38' 3"
Length Overall 40' 6"
Length on Waterline 37' 7"
Beam 13' 0"
Draft 2' 0"
Displacement 13,500 lbs
Water 80 Gallons
Fuel 290 Gallons
Standard Features and Equipment Inventory
HULL:
Patented Shallow draft Performance Hull Design
Docking Skeg for Directional Stability
One Piece Hull Construction
Airex PVC linear foam cored Hull with biaxial laminates
All Hand Laid Fiberglass Laminate
NPG Isophthalic gelcoat
10 Year Hull Laminate Warranty
Full Length Hull Stringer Grid Glassed & Reinforced
Custom Color Boot top
Anti-fouling Bottom Paint and Epoxy Undercoat
MECHANICAL:
Twin Yanmar 4LHY 200HP Diesel Engines (Fresh water cooled)
ZF 2.8:1 Transmission Reduction Gear
(Different engines available in single or twin configuration and surface piercing propellers)
Single Station Hydraulic Steering System
Custom Engine Panels with Gauges
Engine Oil, Water and Gear Temp Audible Alarms
Racor Fuel Filter/Water Separator
Fuel Tank Manifold
Dual Lever Engine Controls
Raw Water Intake Strainers
Heavy Duty Lead Lined Engine Room Sound Insulation
Engine Room Ventilation and Blower
Stainless Steel Propeller Shafts with Zincs
4 Blade Nibral Bronze Propellers
Custom Bronze Propeller Struts
Bronze Rudders with Stainless Steel Shafts
Bronze Rudder Stuffing Boxes
Emergency Steering
UL Listed Seacocks on all Thru Hulls below the Waterline
Hot and Cold Pressure Water System and Shower
6 Gallon Hot Water Heater (110 VAC and Engine Heat Exchanger)
Alloy 5052 Fuel Tanks with Gauges
Rigid Polyvinyl Water Tanks with Gauges
ELECTRICAL:
Six 120 amp hr. Heavy Duty gelcell Marine Batteries
Battery Parallel Switch
Bass AC/DC Master Control Panel with Circuit Breakers, Voltmeters and Ammeters
AC Shore Power 30 AMP Shore Service Inlet and 50' Shore Power Cord and Reverse Polarity Indicator
All Wiring Color Coded to ABYC Codes
Electrical Bonding System with Zinc Anodes
Electric Horn
Navigation Lights with 360 Degree Steaming Light
Bilge Blower in Engine Room
Automatic Bilge Pump
Recessed Interior Lighting
Four 110 VAC GFI Outlets in Interior
Nav Light/Reading Lights
INTERIOR:
Mahogany, cherry, or teak bulkheads (owner choice)with solid trim with 6 coats gloss varnish. Wood hull ceilings finished with satin varnish. Other woods and finishes available as an option.
Owner's choice of interior fabrics.
Owner’s choice of three custom interior layouts
FORWARD STATEROOM:
Double V Berth with filler
Storage under Berth
Two Cedar Lined Hanging Lockers
Drawer bank
Shelves over Berth
Ventilating Hatch/Skylight with Screen/shade
Two Opening Ports with Screens
Forward Cabin Privacy Door with Mirror
Access to Rode Locker
Teak and Holly Sole
Reading and Overhead Lights
110 VAC Outlet
HEAD COMPARTMENT:
Corian Vanity Top (Owner’s choice of color) with stainless steel Sink
Hot/Cold Pressure Water System
Sealand Vacuflush Electric Marine Head with Holding Tank
Holding Tank Deck Pump out
Pull-out Hand-held Shower
Medicine Cabinet Outboard with Shelf and Sliding Door
Bulkhead Mirror over Sink
Stainless Steel Opening Port with Screen
Ventilating Hatch/Skylight with Screen
Overhead Lights
110 VAC Outlet
SALON:
Teak and Holly Sole with Access Hatches
Wrap Around Built-in Convertible Settee/Double Berth to Starboard and Settee/Single Berth to Port - 4” Cushions
Mahogany Salon Table, Drop Leaf
Ten Opening Portlights with Screens
Two Lockers with Liquor Storage and Entertainment center.
Fabric Covered Cushions
Reading and Overhead Lights
Two 110 VAC Outlets
GALLEY:
Corian countertop, owners’ choice of color
Stainless Steel 2 Burner Propane Stove
Stainless Steel 110 VAC Microwave
Refrigerator/Freezer, 110 VAC/12 VDC Front Opening
110 VAC Outlet
Single Large Stainless Steel Sink
Single Lever Hot and Cold Pressure Water Faucet
Large Storage Lockers
Storage Locker and Dish Storage
Cutlery/Utensil Drawer
Trash Bin
DECK AND COCKPIT:
Hand Laid Closed Cell PVC Foam core for Rigidity and Insulation
10 Year Deck Laminate Warranty
Molded-in Nonskid Deck Surface with Recessed Waterways
Contrasting Nonskid Color - owner choice of color
Hull to Deck Joint Mechanically Fastened and Epoxy Sealed
Heavy Duty Rubrail with Stainless Steel Insert
Transom Boarding Door
Cockpit Scuppers
Molded-in Cockpit Steps to Side Decks
Large Cockpit Storage Compartment
Engine access hatch with pneumatic cylinder opener
Custom Anchor Platform with Anchor Roller
Anchor Rode Deck Pipe
Custom Stainless Steel and Teak Side Rails
4 - 10" Mooring Cleats SS
2 – 10" Spring Line Cleats SS
Molded Bulwark and Side Deck Drainage System
Fourteen Opening Ports with Screens
Teak Flag Pole with Holder
Three overhead hatches with screens
Exterior teak finished with Six coats of Gloss Varnish
White Starboard trim available in lieu of exterior teak
HELM STATION/COCKPIT:
Lighted Ritchie Compass
Fully Instrumented Helm Station with Weather-Protected Gauges and Switches
Electronics Layout to Owner Specifications
Dual Lever Engine Controls
Button for Horn
Hydraulic Tilt Steering with Stainless Steering Wheel
Burled Camphor wood Panel
Custom Ultra-suede and stainless steel Helm and Navigator Seats
Wrap Around Lounge Seating for Four
Teak cockpit Table
Custom Stainless Steel Frame/Tinted Safety Glass Windshield
Storage Locker
OUTFIT PACKAGE:
Three Fenders, Four Dock Lines, Anchor with chain and rode, Three Fire Extinguishers, Six Life Jackets, Fog Horn, Flares Kit, First Aid Kit
SPECIFICATIONS AND PRICES SUBJECT TO CHANGE WITHOUT NOTICE 1/10
